Incoloy 825 Plates/Bars/Tubes

Incoloy 825 is widely used in industries that require strong resistance to sulfuric acid, phosphoric acid, and other harsh chemicals, as well as excellent mechanical properties at elevated temperatures. Its high nickel content ensures resistance to stress corrosion cracking, while molybdenum enhances resistance to pitting and crevice corrosion in chloride-containing environments.

Product Parameters

Specification	Details
Material Grade	Incoloy 825
Standard Compliance	ASTM B424, ASTM B425, ASTM B564, ASME SB424, ASME SB425, ASME SB564, UNS N08825, DIN 2.4858
Forms Available	Sheets, Plates, Bars, Pipes, Tubes, Fittings
Size Range	Customizable as per project requirements
Surface Finish	Bright, Annealed, Pickled, Polished
Heat Treatment	Annealed at 940-980°C
Scope of Application	Chemical Processing, Acid Production, Marine Equipment, Heat Exchangers, Pollution Control, Nuclear Waste Processing, Oil & Gas Extraction

Chemical Composition

Element	Composition (%)
Nickel (Ni)	38.0 - 46.0
Iron (Fe)	Balance
Chromium (Cr)	19.5 - 23.5
Molybdenum (Mo)	2.5 - 3.5
Copper (Cu)	1.5 - 3.0
Titanium (Ti)	0.6 - 1.2
Carbon (C)	≤ 0.05
Manganese (Mn)	≤ 1.00
Silicon (Si)	≤ 0.50
Sulfur (S)	≤ 0.03

Physical Performance

• Density: 8.14 g/cm³
• Melting Point: 1370-1400°C
• Thermal Conductivity: 10.8 W/m·K (at 100°C)
• Electrical Resistivity: 1.11 μΩ·m (at 20°C)
• Magnetism: Non-magnetic in annealed condition
• Oxidation Resistance: Excellent resistance to oxidation in oxidizing and reducing environments
• Corrosion Resistance: Superior resistance to acidic and chloride environments

Why Choose Sunning Steel for Incoloy 825?

✅ High-Quality Standards – Manufactured to ASTM, ASME, and UNS specifications.
✅ Custom Processing Available – Cutting, machining, and surface finishing options.
✅ Competitive Pricing – Best value for high-performance nickel alloys.
✅ Global Supply Network – Fast and reliable worldwide shipping.
✅ Dedicated Customer Support – Expert technical and purchasing assistance.
